| Header |
| Manufacturer | Lenovo |
| Model | Universal USB-C Dock |
| Connectivity |
| Connection Technology | Wired |
| Host Interface | USB-C 3.2 Gen 1 (3.1 Gen 1) |
| Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-C Ports | 1 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-A Ports | 3 |
| Number of HDMI Ports | 1 |
| Microphone, Line-In Jack | No |
| Number of DisplayPorts | 2 |
| Combined Headphone/Microphone Port | Yes |
| Performance |
| Product Color | Black |
| Built-in Card Reader | No |
| Maximum Digital Resolution | 3840 x 2160 pixels |
| Kensington Lock Type | Kensington |
| Kensington Lock Port | Yes |
| Number of Supported Monitors | 3 |
| HD Type | 4K/UHD |
| Certification | FCC/ICES CE KCC RCM BSMI VCCI CB cULus EAC TUV- Mark Serbia Quality LoA Israel SII Ukraine DoC NOM |
| Power Button | Yes |
| Networking |
| Number of Ethernet/Broadband Connections (RJ-45) | 1 |
| Ethernet/Broadband Connection | Yes |
| Ethernet LAN Data Transfer Rates | 10, 100, 10, 100, 1000 Mbit/s |
| Power Management |
| Power Source Type | USB |
| Power Connection | USB Type-C |
| Power Supply Requirements | 90 W |
| Weight and Dimensions |
| Width | 171 mm |
| Depth | 80 mm |
| Height | 30.75 mm |
| Weight | 388 g |
| Logistics Data |
| Harmonized System (HS) Code | 84733020 |
| Software |
| Supported Windows Operating Systems | Windows 10, Windows 10 x64, Windows 8.1, Windows 8.1 x64, Windows 8, Windows 8 x64, Windows 7, Windows 7 x64, Windows Server 2016, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2, Windows Server 2008, Windows Server 2008 x64, Windows 7, 8.1, 10, 11, Server 2008R2, 2012, 2012R2, 2016, 2019, 2022, 2025 |
| Packaging Contents |
| Cables Included | USB Type-C |
| Environmental Conditions |
| Relative Humidity Operating (H-H) | 20 - 95 % |
| Operating Temperature (T-T) | 0 - 35 °C |
| Data Packaging |
| Number per Package | 1 pc(s) |
| Package Width | 210 mm |
| Package Depth | 158 mm |
| Package Height | 75 mm |
| Package Weight | 955 g |
| Technical Details |
| CE, FCC, IC |
